A HIGHLY RELIABLE, SOLID-STATE WEATHER SENSOR TO MONITOR LIVE CONDITIONS ACROSS YOUR COVERAGE AREA
Delivering Accurate Weather Data from the Most Demanding Sites
SENSORS WORK SEAMLESSLY WITH EACH WXVISION CAMERA
WxVision’s data is the best way to integrate weather information from your viewing area into forecasts and real-time coverage. With continuous live reporting of weather measurements at keylocations within your market, sensors seamlessly work together with each WxVision camera.
The WxVision Weather Sensor integrates the six most essential weather parameters into one instrument uniquely designed with no moving parts.
- Wind Speed and Direction
- Air and Wind Chill Temperatures
- Barometric Pressure
- Relative Humidity
- Dew Point
- Heat Index
HIGHLY RELIABLE SOLUTION ABLE TO WITHSTAND CHALLENGING ENVIRONMENTS
- Rugged, anti-corrosive materials accurate from -40oto +176oF
- Sonar wind sensor confirmed accurate to 89mph winds
- Impact rain sensor
- WxVision software package (per weather station)
- Smart Encoder for data relay
- Up to 300ft of cabling for installation
SEE HOW STATIONS USE LIVE WEATHER DATA ON-AIR
MOBILE WEATHER SENSOR
1
2
3
4
5
-
- Reports wind speed and direction, air temperature w/ wind chill & heat index, barometric pressure, relative humidity, and dew point
- Rapid response time and refresh rate
- Accurate and stable theoretical wind and heading data in changing conditions
- Solid state compass with GPS
- Compact and waterproof – single cable installation
SPECIFICATIONS
Wind Speed
• Wind Speed Range: 0 MPH to 90 MPH (0 knots to 78 knots)
• Wind Speed Accuracy @ 32°F to 131°F (0°C to 55°C)
Low Wind Speeds: 0 MPH to 11.5 MPH; 1.1MPH +10% of reading
High Wind Speeds: 11.5 MPH to 90 MPH; 2.3 MPH or 5%, whichever is greater
Wind Direction
• Wind Direction Range: 0° to 360°
• Wind Direction Accuracy @ 32°F to 131°F (0°C to 55°C)
Low Wind Speeds (5° RMS typical): 4.6 MPH to 11.5 MPH, 2 m/s to 5 m/s
High Wind Speeds (2° RMS typical): >11.5 MPH, >5 m/s
Air Temperature
• Air Temperature Range: -40°F to 131°F (-40°C to 55°C)
• Air Temperature Accuracy: ±2°F (±1.1°C) @ >4.6 MPH wind
Barometric Pressure
• Barometric Pressure Range: 300 mbar to 1100 mbar
• (24 inHg to 33 inHg, 800 hPa to 1100 hPa)
Relative Humidity Data
• Relative Humidity Range: 10% to 95% RH
GPS Data
• GPS Position Accuracy: 3 m (10’) with WAAS/EGNOS
Request a Demo
Let’s talk about how we can improve the quality, ease, and responsiveness of your live local, national, and international content with end-to-end solutions.
